S&M Bikes BTM XL Frame

$929.00

Brand: S & M bikes

Red/Gold / 21

S&M Bikes BTM XL Frame

USA MADE


TOP TUBE LENGTH 21″,21.25″,21.5″
REAR END LENGTH 13.05-13.50″
HEAD TUBE ANGLE 75°
HEAD TUBE STYLE  5″ Integrated (45°/45°, 41.8mm)
SEAT TUBE ANGLE 71°
SEAT CLAMP Slotted for traditional clamp
SEAT POST SIZE 1″ (25.4mm)
BB HEIGHT 11.5″
BB STYLE Mid
STANDOVER HEIGHT 9.50″
BRAKE MOUNTS  Thread-On 990 Mounts (sold separately)
DROPOUTS 14mm Slot, 4Q-Baked
GYRO TABS None
WEIGHT 5.4 lb (2.45 kg)
TUBESET Butted Thermal-X
